Description
Technical Data:
| Lifting Capacity |
8000lbs. (3500 KG) |
|
Lifting Height |
70.87 inch (1800 mm) |
|
Min. Height |
4.72 inch (120 mm) |
|
Height Overall |
83.22 inch (2114 mm) |
| Plateform Length | 163.39 inch (4150 mm) |
| Length Overall | 205.19 inch (5212 mm) |
|
Plateform Width |
74.61 inch (1895 mm) |
| Width Overall | 116.18 inch (2951 mm) |
| Into The Car Width | 92.87 inch (2359 mm) |
|
Motor |
According to Customer needs |
|
Net Weight |
1587 lbs (720 KG) |
Feature :
● 8000lbs(3500KG) lifting capacity
● CE Approved and Certified,it has adopted 115% dynamic loading capacity and 150% staic loading capacity tested.
● Simple but reliable design. User friendly, easy on-site installation
● Mechanical locks automatically engaged into position in up process
● Single hydraulic cylinder mounted underneath runway
●One side release for safety locks, easy for descent operation
● Top level hydraulic system and motor with 220V/60HZ/1PH and 110V/60HZ/1PH(Optional)
